Mercedes work just got a lot easier for KORHEX owners. Flex release 8.17.0.0 enables Boot Glitch mode for the Mercedes Bosch MD1CP001 and MG1CP002, both built on SPC5777 processors, using KORHEX and its EMFI (Electromagnetic Fault Injection) technology.
Leave the board alone
This method makes reaching the unit far simpler. You don't solder on the circuit board and you don't remove components, which means fewer steps and more independence in your shop.
Position KORHEX, follow the guided procedure in Flex, and you're into the SPC5777 microprocessor.
License requirements
These operations require either the FLS0.20 license or the Flex Full FLS0.5 configuration.
Specs
- Supported units: Mercedes Bosch MD1CP001 (SPC5777) and Mercedes Bosch MG1CP002 (SPC5777)
- Working mode: Boot Glitch
- Memory operations: internal flash read/write/checksum, internal EEPROM read/write, full backup
- Licenses: FLS0.20M/S, FLS0.5M/S
- Connect/glitch time: about 40 seconds
- Read time: about 2 minutes
- Write time: about 2 minutes
Example vehicles
- MY2021 Mercedes A-Class (W177) A 220 d, 2.0L 16v, 187 hp
- MY2022 Mercedes GLA-Class (H247) GLA 200 d, 2.0L 16v, 148 hp
- MY2021 Mercedes Vito (W447) 116 CDI, 2.0L 16v, 161 hp
- MY2021 Mercedes-AMG A 45 (W177), 2.0L 16v, 382 hp
- MY2023 Mercedes-AMG CLE 53 (C236), 3.0L 24v MHEV, 465 hp
Add KORHEX to your bench with Viezu USA
Need KORHEX, the right mask, or help deciding between the FLS0.20 Boot Glitch license and Flex Full? Viezu USA sells Magic Motorsport KORHEX and Flex products and can help you put together the right setup. Shop or contact Viezu USA at viezuusa.com.
